This 60V40Ah lithium battery is produced by Lithium Battery, a leading manufacturer based in China that focuses on high-quality lithium-ion batteries. Adopting advanced NCM technology, this battery features outstanding performance and reliability, making it an ideal choice for a wide range of applications.
Key features:
High energy output: With a rated capacity of 40Ah and an energy output of 2,448Wh, this battery can provide sufficient power for demanding applications.
Durable building: The battery has an IP65 rating, ensuring dust and water resistance, and is suitable for outdoor and industrial applications.
Long lifespan: Capable of over 4,000 cycles at 80% depth of discharge (DOD), this battery minimizes the need for frequent replacement and holds significant value.
Intelligent Battery Management System (BMS) : Equipped with advanced BMS, it can prevent overcurrent, overcharging and overheating, ensuring safe operation.
Integrated GPS function: This battery is equipped with a built-in GPS function, which can track and monitor your power supply in real time.
60V 30Ah LiFePO4 lithium battery Suitable for various applications, including:
· Electric scooter
· Electric pedal carts and electric tricycles
· Electric motorcycles
· Automated Guided Vehicles (AGV)
· Solar power generation systems and off-grid life
· Electric forklifts and ship applications
The charging voltage is 71.4V and the discharging cut-off voltage is 46.75V. This battery has been optimized for various operational requirements. It can operate from -10°C to 50 °C, making it suitable for various environments. The lightweight design of the battery makes it easy to install and integrate into existing systems, while ensuring your device operates efficiently throughout the day. In addition, it also supports a fast charging function, thereby reducing the turnaround time between uses.
Committed to providing high-quality lithium-ion batteries to enhance your operational efficiency and sustainability. The 60V 40Ah lithium battery not only reduces downtime but also helps lower operating costs due to its high efficiency and long service life. Investing in this battery means choosing a reliable power solution that not only meets the demands of modern electric vehicles and industrial applications but also supports your business growth and sustainable development goals.
| LFP TO REPLACE VRLA BATTERY FOR ELECTRIC SCOOTER -AOGE 60V LPES SERIES | |
| MODEL | AG6040LFP-LPES |
| Rated Voltage | 61.2V |
| Rated Capacity | 40Ah |
| Rated Energy | 2448Wh |
| MAX.Charge Voltage | 71.4V |
| RECMD charge current(0.2C) | 10A |
| RECMD charge METHOD | At 0℃-45℃, Set up charge voltage at 71.4V, and initial charge-current at 0.2C; change battery continuously till the current drops less 0.02C |
| Max.Charge Current(0.5C) | 20A |
| Discharge CUT-OFF Volt. | 46.75V |
| RECMD discharge current(0.2C) | 10A |
| Max.Discharge Current(1C) | 40A |
| Peak discharge current(2C) (MAX. 3 second) | 80A |
| Dimensions(L*W*H*TH)MM | 220*160*295 |
| Weight(APPROX)KG±3% | 20kg |
| Max. Parallel and Series QTY | NOT RECOMMENDED |
| IP Rating | IP65 |
| Cycle Life | >4000 cycles @0.2C Charging/Discharging (DOD 80%) |
| Self-Discharge | ≦2% (per month) |
| Charge/storage Temperature | 0°C ~ 45°C @60±25% Relative Humidity |
| Discharge Temperature | -20°C ~ 60°C @60±25% Relative Humidity |
| Optional Functions | Bluetooth / App / WiFi / 4G / GPS / Self-heating / LCD/RS485/RS232/CAN-BUS/etc. |
| JBD/DALY BMS FUNCTION | Over current/Over charge/Over discharge/Over load/Over voltage/Low voltage/Over heat/Over temperature/Low temperature/etc. |
| Terminal | M8 |
| Battery Case | METAL WITH GPS/4G |
| Design Life/WARRANTY | 10 Years/3 YEARS |
