48V (51.2V) 100Ah lithium battery 8D
Category: 48v RV lithium battery
Lithium battery: Lithium iron phosphate (LFP)
Rated voltage: 51.2V
Capacity:100Ah
Nominal energy:5120Wh
Dimensions (length x width x height):523×270×220 mm
Weight: 39 KG/86 lb
IP Rating: IP65
This 48V (51.2V) 100Ah lithium battery 8D is from Aoge Power, a renowned manufacturer based in China that specializes in high-quality lithium-ion batteries. Utilizing advanced LiFePO4 technology, this battery offers reliable energy solutions for various applications, ensuring outstanding performance and safety.
Key features:
High energy capacity: With a rated capacity of 100Ah and an energy output of 5,120Wh, this battery is highly suitable for powering demanding equipment and systems.
Outstanding cycle life: The designed service life exceeds 4,000 cycles when the depth of discharge (DOD) reaches 80%, significantly reducing the need for frequent replacement.
Durable building: The battery has an IP65 rating, which can prevent dust and water from entering and is suitable for use in challenging environments.
Intelligent Battery Management System (BMS) : Equipped with an intelligent BMS, it can prevent overcharging, overheating and short circuits, ensuring safe operation.
Multi-functional connection options: Supports optional functions such as Bluetooth, WiFi, and LCD display to enhance monitoring and control.
Application
48V 100Ah lithium battery 8D is suitable for various applications, including:
· Electric scooter
· Electric pedal carts and electric tricycles
· Electric motorcycles
· Automated Guided Vehicles (AGV)
· Floor cleaning machines
The charging voltage is 58.4V and the discharge voltage is 40V. This battery has been optimized for various operational requirements. It can operate from -20°C to 65°C, making it flexible enough to be suitable for different industrial environments. The lightweight design of the battery facilitates installation and integration into existing systems.
Its high performance ensures that your equipment operates efficiently throughout the day. Additionally, the battery supports fast charging, which can shorten the turnaround time between uses. As a reliable factory in China, Aoge Power is committed to providing high-quality lithium-ion batteries to enhance your operational efficiency and sustainability. 48V 100Ah lithium battery 8D not only reduces downtime but also helps lower operating costs due to its high efficiency and long lifespan.
Investing in this battery means choosing a reliable power solution that can meet the needs of modern electric vehicles and industrial applications, and support your business growth and sustainability goals.
| LFP TO REPLACE VRLA BATTERY FOR RECREATIONAL VEHICLE/GOLF CART -AOGE 48V LPRV/LPGC SERIES | |
| MODEL | AG48100(I)LFP-LPRV |
| Rated Voltage | 51.2V |
| Rated Capacity | 100Ah |
| Rated Energy | 5120Wh |
| MAX.Charge Voltage | 56-58.4V |
| RECMD charge current(0.2C) | 20A |
| RECMD charge METHOD | At 0℃-45℃, Set up charge voltage at 58.4V, and initial charge-current at 0.2C; change battery continuously till the current drops less 0.02C |
| Max.Charge Current(0.5C) | 100A |
| Discharge CUT-OFF Volt. | 40V |
| RECMD discharge current(0.2C) | 20A |
| Max.Discharge Current(1C) | 100A |
| Peak discharge current(2C) (MAX. 3 second) | 200A |
| Dimensions(L*W*H*TH)MM | 523*270*220 |
| Weight(APPROX)KG±3% | 39KG |
| Max. Parallel and Series QTY | 4P/4S |
| IP Rating | IP65 |
| Cycle Life | >4000 cycles @0.2C Charging/Discharging (DOD 80%) |
| Self-Discharge | ≦2% (per month) |
| Charge/storage Temperature | 0°C ~ 45°C @60±25% Relative Humidity |
| Discharge Temperature | -20°C ~ 60°C @60±25% Relative Humidity |
| Optional Functions | Bluetooth / App / WiFi / 4G / GPS / Self-heating / LCD/RS485/RS232/CAN-BUS/etc. |
| JBD/DALY BMS FUNCTION | Over current/Over charge/Over discharge/Over load/Over voltage/Low voltage/Over heat/Over temperature/Low temperature/etc. |
| Terminal | M8 |
| Battery Case | ABS |
| Design Life/WARRANTY | 10 Years/3 YEARS |
