25.6/51.2V LOW VOLTAGE WALL MOUNTED WALL SERIES SINGLE BATTERY
Supports over 6,000 charge cycles at 80% Depth of Discharge (DOD). Operates seamlessly in temperatures ranging from -4°F to 167°F. Equipped with a Battery Management System (BMS) for protection against overcharging, short circuits, and extreme temperatures. IP56+ rating ensures reliability for both indoor and outdoor environments. Lightweight and space-efficient, making installation quick and easy.
Type: LiFePO4 Battery
Usage: Electric Power, Electric Bicycle, Boat, Motorcycle
Minimum Order Quantity: 50
Delivery Time: 20 days
Customization/OEM/ODM: Yes
Factory:AOGE POWER
Delivery Method: FOB, EXW, CIF
Payment Method: T/T, L/C, PayPal
Shipping Methods: 10 feet, 20 feet, 40 feet, 60 feet
The 200Ah 25.6V 5.12KWH LiFePO4 Power Wall Battery product is a cutting-edge solution designed to meet the growing demand for efficient and sustainable energy storage in residential settings. With a rated power of 1000W, this system is equipped with a 5KW Hybrid Inverter that ensures optimal energy conversion and utilization.
One of the key features of this product is its versatility in handling varying levels of humidity, with a range from 10% to 90%. This makes it suitable for a wide range of climates and environmental conditions, providing reliable performance regardless of the weather.
Long-Lasting Battery Life and a Solid Warranty :They can go through over 6,000 charge cycles, so you can count on them for a long time. And with a strong 5-year warranty, you don’t have to worry about replacing them often.
Monitoring & Protection Smart BMS: Overcharge / OverDischarge / Overcurrent / OverTemperature / ShortCircuit
Communication : RS485 / RS232 / CAN-bus
Optional Functions :Bluetooth / WiFi / 4G / 5G / Circuit Breaker / Heating / Active Balance / LED Touch Screen / APP
Accessories : Inverter Power Cable, Parallel Cable, Communication Cable, Grounding Wire
Compatible Inverters :Victron / GOODWE / Solis / Growatt / SMA / SAJ / Luxpower / SRNE / Deye / Voltronic, etc.
Product Description
The capacity energy of this Residential Energy Storage system is 5.12 KWh, offering ample storage for excess energy generated through solar panels or other renewable sources. With an energy storage capacity ranging from 10 KWh to 20 KWh, this product is a robust and efficient solution for homeowners looking to maximize their energy independence.
As a leading Domestic Energy Storage Solution, this product is designed to seamlessly integrate with residential solar battery storage systems, enabling users to store excess energy generated during the day for use during peak hours or in case of power outages. This not only reduces reliance on the grid but also helps lower electricity bills and minimize the carbon footprint of households.
Whether you are looking to enhance the efficiency of your solar energy system or simply want a reliable backup power source for your home, the Residential Energy Storage product offers a comprehensive solution that combines cutting-edge technology with user-friendly design. With its high-rated power, advanced inverter, and versatile storage capacity, this system is the ideal choice for homeowners seeking a reliable and sustainable energy storage solution.
AOGE 25.6/51.2V LOW VOLTAGE WALL MOUNTED WALL SERIES SINGLE BATTERY | |||||
Model | AG25100LFP-WMLV | AG25200LFP-WMLV | AG25306LFP-WMLV | AG51100LFP-WMLV | AG51200LFP-WMLV |
Cell Format | LFP3.2V100AH/8S1P | LFP3.2V200AH/8S1P | LFP3.2V306AH/8S1P | LFP3.2V100AH/16S1P | LFP3.2V200AH/16S1P |
Rated Voltage | 25.6V | 51.2V | |||
Rated Capacity | 100Ah | 200Ah | 306Ah | 100Ah | 200Ah |
Rated Energy | 2.56KWh | 5.12KWh | 7.83KWh | 5.12KWh | 10.24KWh |
Charge Voltage | 28.4-29.2V | 56.8-58.4V | |||
RCMD Charge Current | 25A | 50A | 50A | 25A | 50A |
Max Charge Current | 50A | 100A | 150A | 100A | 100A |
Discharge Cut-off Volt. | 21.6V | 43.2V | 43.2V | ||
Max Discharge Current | 50A | 100A | 150A | 100A | 100A |
Dimension (L*W*H) | 435*385*145MM | 650*385*145MM | 650*450*200MM | 650*385*145MM | 680*415*235MM |
Weight(APPROX.)KG±5% | 25kg | 45kg | 65kg | 45kg | 95kg |
Charge Temperature | 0℃to 55℃ | ||||
Operate Temperature | -10℃to 60℃ | ||||
Storage Temperature | 0℃to 40℃ | ||||
Environmental | <95%RH | ||||
Protection Rating | IP20 | ||||
Cycle Life | 8000Cycle@25℃,60%DOD,0.2C | ||||
6000Cycle@25℃,80%DOD,0.2C | |||||
Scalability | Max 16 parallel | ||||
Design life/Warranty | 10 years / 5 years | ||||
Cell | IEC62619/UL1642 | ||||
Battery Pack | UN38.3/CE/IEC62619/IEC61000 | ||||
Display | SOC status indicator,LED indicator | ||||
Communication | CAN/RS485/RS232 | ||||
Optional Functions | bluetooth/wifi/lcd/circuit breaker | ||||
Compatible inverter | victron/sol-ark/SMA/GOODWE/SOLIS/SAJ/GROWATT/SRNE/VOLTRONIC/DEYE/ETC. | ||||
Display | SOC status indicator,LED indicator | ||||
Communication | CAN/RS485/RS232 | ||||
Optional Functions | bluetooth/wifi/lcd/circuit breaker | ||||
Compatible inverter | victron/sol-ark/SMA/GOODWE/SOLIS/SAJ/GROWATT/SRNE/VOLTRONIC/DEYE/ETC. |
