Aoge Power 24V 100Ah LiFePO4 lithium battery is specially designed for floor scrubbers and cleaners, providing reliable power for demanding applications. With its advanced functions and customizable options, this battery is an excellent choice for OEM, ODM and wholesale buyers seeking efficient energy solutions.
Key features:
Large capacity: The rated capacity is 100Ah, ensuring sufficient energy for the floor cleaning machine.
Long lifespan: More than 5000 cycles with a discharge depth (DoD) of 80% can ensure durability and long service life.
IP65 rating: With dust and water protection features, it is suitable for use in various environments.
Intelligent BMS protection: Equipped with a comprehensive battery management system (BMS) to enhance safety and performance.
Product description
The nominal voltage of the 24V 100Ah LiFePO4 lithium battery is 25.6V and its energy output is 2560Wh. It is highly suitable for powering floor washers and other cleaning machines. The weight of this battery is approximately 25 kg. It is constructed with a sturdy metal casing to ensure durability in harsh conditions. The intelligent BMS of this battery can prevent overcharging, overheating and short circuits, ensuring safe operation during use. OEM/ODM buyers can choose custom options, including Bluetooth connection and self-heating functions, etc. By choosing Aoge Power high-performance battery solution, you can effectively meet your energy needs and enhance the productivity of cleaning equipment.
| LFP BATTERY TO REPLACE VRLA BATTERY FOR RECREATIONAL VEHICLE -AOGE 24V LPRV SERIES | |
| MODEL | AG24100(II)LFP-LPRV |
| Rated Voltage | 25.6V |
| Rated Capacity | 100Ah |
| Rated Energy | 2560Wh |
| MAX.Charge Voltage | 28-29.2V |
| RECMD charge current(0.2C) | 20A |
| RECMD charge METHOD | At 0℃-45℃, Set up charge voltage at 29.2V, and initial charge-current at 0.2C; change battery continuously till the current drops less 0.02C |
| Max.Charge Current(0.5C) | 100A |
| Discharge CUT-OFF Volt. | 20V |
| RECMD discharge current(0.2C) | 20A |
| Max.Discharge Current(1C) | 100A |
| Peak discharge current(2C) (MAX. 3 second) | 200A |
| Dimensions(L*W*H*TH)MM | 523*240*220 |
| Weight(APPROX)KG±3% | 25KG |
| Max. Parallel and Series QTY | 4P/4S |
| IP Rating | IP65 |
| Cycle Life | >5000 cycles @0.2C Charging/Discharging (DOD 80%) |
| Self-Discharge | ≦2% (per month) |
| Charge/storage Temperature | 0°C ~ 45°C @60±25% Relative Humidity |
| Discharge Temperature | -20°C ~ 60°C @60±25% Relative Humidity |
| Optional Functions | Bluetooth / App / WiFi / 4G / GPS / Self-heating / LCD/RS485/RS232/CAN-BUS/etc. |
| JBD/DALY BMS FUNCTION | Over current/Over charge/Over discharge/Over load/Over voltage/Low voltage/Over heat/Over temperature/Low temperature/etc. |
| Terminal | M8 |
| Battery Case | ABS |
| Design Life/WARRANTY | 10 Years/3 YEARS |
