Forklift lithium batteries 25.6V, 24V, 560Ah, 550Ah, 500Ah
Category: 24v Forklift lithium battery
It is used for forklifts, pallet trucks, pallet trucks, and to replace lead-acid batteries in forklifts with lithium iron phosphate batteries, etc.
Minimum order quantity: 1
Delivery: 20 days
OEM/ODM: Yes
Delivery terms: FOB price, free price, landed price
Payment: Telegraphic transfer, paypal
Air/Sea freight: 10 feet, 20 feet, 40 feet, 40 feet HC and 45 feet
25.6V 560Ah for Forklift Battery Provides high performance, durability and efficiency for modern material handling applications. This lithium iron phosphate (LiFePO4 560) battery has a nominal capacity of 4Ah and is designed to be robust, ensuring the power of the forklift and providing reliability in both indoor and outdoor operations. This battery is an ideal choice for OEM, ODM and wholesale buyers. It is an environmentally friendly and long-lasting solution that can reduce maintenance costs and support sustainable operations.
Main Features
High capacity and long service life: 25.6V, 560Ah capacity, capable of over 80 charge cycles at a depth of discharge (DOD) of 4000%, to achieve a long service life and reliability.
Powerful performance: Charging current of 350A, continuous discharge current of 350A, peak discharge current of 500A (30 seconds), making it highly suitable for demanding material handling tasks.
Advanced protection: The equipped battery management system (BMS) ensures safety through functions such as overcharge, overdischarge, overcurrent and temperature protection.
Environmentally friendly and durable: This forklift battery is made of LiFePO4 battery, which is both environmentally friendly and can withstand harsh working conditions, with a water and dust resistance rating of IP65.
Customizable and flexible: Suitable for OEM/ODM projects, it features customizable designs, capacity options (550Ah, 500Ah), and various delivery terms (FOB, CIF, EXW).
Application
25.6V 560Ah forklift lithium battery is a high-performance power solution specifically designed for material handling operations. This LiFePO4 lithium battery is engineered for durability and can provide over 80 cycles at a 4000% discharge depth (DOD). It offers consistent high power output, with a continuous charging and discharging current of 350A, and a peak current of up to 500A for 30 seconds. It is ideal for forklifts in warehouses, distribution centers, and outdoor environments.
The compact design of the battery (778 x 324 x 570 mm, approximately 385 kg) ensures that it can be easily installed in various forklift models. At the same time, its IP65 industrial packaging grade guarantees that it can withstand dust and water erosion. Its natural cooling system does not require additional cooling equipment, making it both economical and suitable for long-term operation.
With a wide operating temperature range (-20°C to 60°C), the 25.6V 560Ah forklift lithium battery can cope with the working environment without affecting performance. The battery management system continuously monitors the voltage, current and temperature of the system, protecting the battery from overcharging, overdischarging and short circuits, ensuring safe operation in harsh conditions.
This forklift lithium battery is highly suitable for OEM, wholesalers and ODM projects. It offers flexible customization options and is compatible with various capacities, voltages and communication protocols (RS485, CAN bus, 4G). The battery also comes with a 5-year warranty, providing peace of mind for bulk purchasers.
For those seeking a reliable, economical and environmentally friendly power solution, the 25.6V 560Ah forklift lithium battery is the ideal choice to meet the current material handling requirements.
| 24V 560AH Lithium Battery | Specifications |
| Model | AG24560LFP-LPFK |
| Lithium Battery Type | Lithium Iron Phosphate (LFP) |
| Rated Voltage | 24V |
| Rated Capacity | 560Ah |
| Nominal Energy | 13.44KWh |
| Maximum Charging Voltage | 29.4 |
| Discharge Cut-off Voltage | 20V |
| Maximum Continuous Charging Current | 112A |
| Maximum Continuous Discharging Current | 112A |
| Peak Discharging Current | 280A (for 10 seconds) |
| Dimensions [Length x Width x Height] | 718×370×270mm |
| Weight | 123kg |
| IP Rating | IP65 |
| Cycle Life | >6000 cycles (80% DOD) |
| Self-discharge | 2% (per month) |
| Charging Temperature | 0°C~60°C |
| Discharging Temperature | -20℃~60℃ |
| Optional Features | Self-heating / Bluetooth / APP / WiFi / 4G / GPS / RS485 / RS232 / CAN bus / Active balancing / Anti-theft / Solar MPPT / Solar panels / Inverter / Fan cooling / Radiator / etc. |
| Charger | Yes |
| BMS | Intelligent BMS: Overcurrent, Overcharge, Overdischarge, Overload, Overvoltage, Undervoltage, Over-temperature, Overheat, etc. |
| Battery Case | Metal |
| Design Life | 10 years |
| Silk Screen Printing / Label / Laser Logo | Yes |
| User Manual | Yes |
| OEM / ODM | Yes |
| Shipping | Yes |
| Company Certifications | UL1642 / IEC62133 / CE / RoHS / UN38.3 / MSDS |
